#12651 PDGF Receptor Activation Antibody Sampler Kit


CSTコード 包装
希望納入価格 (円)
国内在庫 i
2019年3月20日11時40分 現在
ご登録代理店情報 i
カスタマー情報にご登録いただいた代理店を表示しています。
ご登録代理店の変更はこちら
#12651T1 Kit107,000
ログインすると国内在庫状況がご確認いただけます。

PDGFR 製品一覧

12651 の推奨プロトコール i

最適な結果を得るために:Cell Signaling Technology (CST) 社は、各製品の推奨プロトコールを使用することを強くお薦めいたします。
推奨プロトコールはCST社内試験の徹底的なバリデーションに基づいて作成されておりますので、正確かつ再現性の高い結果が得られます。

注:各製品に最適化されたプロトコールをリンクしています。


キット内容 容量 用途 種交差性 ホモロジー† 検出分子量 アイソタイプ
Phospho-PDGF Receptor β (Tyr751) (C63G6) Rabbit mAb #4549 20 µl WB H, M R 190 Rabbit IgG
PDGF Receptor β (28E1) Rabbit mAb #3169 20 µl WB, IP, IHC-P, IHC-F, IF-IC H, M, R 190 Rabbit IgG
Phospho-SHP-2 (Tyr542) Antibody #3751 20 µl WB, IP H, M, R Mk, C, X 72 Rabbit
SHP-2 (D50F2) Rabbit mAb #3397 20 µl WB, IP, IHC-P H, M, R, Mk 72 Rabbit IgG
Phospho-Akt (Ser473) (D9E) XP® Rabbit mAb #4060 20 µl WB, IP, IHC-P, IF-IC, F H, M, R, Hm, Mk, Dm, Z, B C, X, Dg, Pg 60 Rabbit IgG
Akt (pan) (C67E7) Rabbit mAb #4691 20 µl WB, IP, IHC-P, IF-IC, F H, M, R, Mk, Dm Pg 60 Rabbit IgG
Phospho-p44/42 MAPK (Erk1/2) (Thr202/Tyr204) (D13.14.4E) XP® Rabbit mAb #4370 20 µl WB, IP, IHC-P, IF-IC, F H, M, R, Hm, Mk, Mi, Dm, Z, B, Dg, Pg, Sc C, Ce 44, 42 Rabbit IgG
p44/42 MAPK (Erk1/2) (137F5) Rabbit mAb #4695 20 µl WB, IP, IHC-P, IF-IC, F H, M, R, Hm, Mk, Mi, Dm, Z, B, Dg, Pg, Ce C 42, 44 Rabbit IgG
Anti-rabbit IgG, HRP-linked Antibody #7074 100 µl WB Goat

†Species predicted to react based on 100% sequence homology.

Applications Key: W=Western Blotting, IP=Immunoprecipitation, IHC-P=Immunohistochemistry (Paraffin), IHC-F=Immunohistochemistry (Frozen), IF-IC=Immunofluorescence (Immunocytochemistry), F=Flow Cytometry
Reactivity Key: H=Human, M=Mouse, R=Rat, Mk=Monkey, Hm=Hamster, Dm=D. melanogaster, Z=Zebrafish, B=Bovine, Mi=Mink, Dg=Dog, Pg=Pig, Sc=S. cerevisiae, Ce=C. elegans

貯法
-20℃
社内データ

Western Blotting

Western Blotting

After the primary antibody is bound to the target protein, a complex with HRP-linked secondary antibody is formed. The LumiGLO® is added and emits light during enzyme catalyzed decomposition.

Western Blotting

Western Blotting

Western blot analysis of extracts from C6 and NIH/3T3 cells, starved for 18 hours and either untreated or PDGF-treated (50ng/ml, 20 minutes), using Phospho-SHP-2 (Tyr542) Antibody (upper) or control SHP-2 Antibody #3752 (lower).

Western Blotting

Western Blotting

Western blot analysis of extracts from HeLa, NIH/3T3 and C6 cells, using p44/42 MAPK (Erk1/2) (137F5) Rabbit mAb.


Western Blotting

Western Blotting

Western blot analysis of extracts from various cell lines, using PDGF Receptor β (28E1) Rabbit mAb.

Western Blotting

Western Blotting

Western blot analysis of extracts from PC-3 cells, untreated or LY294002/wortmannin-treated, and NIH/3T3 cells, serum-starved or PDGF-treated, using Phospho-Akt (Ser473) (D9E) XP® Rabbit mAb (upper) or Akt (pan) (C67E7) Rabbit mAb #4691 (lower).

Western Blotting

Western Blotting

Western blot analysis of recombinant Akt1, Akt2 and Akt3 proteins, and extracts from various cell lines, using Akt (pan) (C67E7) Rabbit mAb.


Western Blotting

Western Blotting

Western blot analysis of extracts of NIH/3T3 cells, untreated or stimulated with Platelet-Derived Growth Factor (PDGF) #9909, using Phospho-PDGF Receptor-β (Tyr751) (C63G6) Rabbit mAb (upper) or PDGF Receptor-β (2B3) Mouse mAb #3175 (lower).

Western Blotting

Western Blotting

Western blot analysis of extracts from COS cells, untreated or treated with either U0126 #9903 (10 µM for 1h) or TPA #4174 (200 nM for 10 m), using Phospho-p44/42 MAPK (Erk1/2) (Thr202/Tyr204) (D13.14.4E) XP® Rabbit mAb #4370 and p44/42 MAPK (Erk1/2) (3A7) Mouse mAb #9107.

Western Blotting

Western Blotting

Western blot analysis of extracts from various cell lines using SHP-2 (D50F2) Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human colon carcinoma using PDGF Receptor β (28E1) Rabbit mAb.

Western Blotting

Western Blotting

Western blot analysis of extracts from 293, NIH/3T3 and C6 cells, treated with λ phosphatase or TPA #4174 as indicated, using Phospho-p44/42 MAPK (Erk1/2) (Thr202/Tyr204) (D13.14.4E) XP® Rabbit mAb (upper), or p44/42 MAPK (Erk1/2) (137F5) Rabbit mAb #4695 (lower).

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded MDA-MB-468 xenograft using Phospho-Akt (Ser473) (D9E) XP® Rabbit mAb (left) or PTEN (138G6) Rabbit mAb #9559 (right). Note the presence of P-Akt staining in the PTEN deficient MDA-MB-468 cells.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human melanoma using Akt (pan) (C67E7) Rabbit mAb.

Western Blotting

Western Blotting

Western blot analysis of extracts from Hek 293 cells, transfected with 100 nM SignalSilence® Control siRNA (Fluorescein Conjugate) #6201 (-) or SignalSilence® p44/42 MAPK (Erk1/2) siRNA (+), using p44/42 MAPK (Erk1/2) (137F5) Rabbit mAb #4695 and α-Tubulin (11H10) Rabbit mAb #2125. The p44/42 MAPK (Erk1/2) (137F5) Rabbit mAb confirms silencing of p44/42 expression and α-Tubulin (11H10) Rabbit mAb is used to control for loading and specificity of p44/42 MAPK (Erk1/2) siRNA.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human breast carcinoma using SHP-2 (D50F2) Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human breast carcinoma, showing cytoplasmic and nuclear localization, using p44/42 MAPK (Erk1/2) (137F5) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human glioblastoma using PDGF Receptor β (28E1) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human breast carcinoma using Akt (pan) (C67E7) Rabbit mAb in the presence of control peptide (left) or Akt (pan) Blocking Peptide #1085 (right).


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human breast carcinoma using Phospho-p44/42 MAPK (Erk1/2) (Thr202/Tyr204) (D13.14.4E) XP® Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human breast carcinoma comparing SignalStain® Antibody Diluent #8112 (left) to TBST/5% normal goat serum (right) using Phospho-Akt (Ser473) (D9E) XP® Rabbit mAb #4060.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded K-562 cell pellet (left, high-expressing) or Saos-2 cell pellet (right, low-expressing) using SHP-2 (D50F2) Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human colon carcinoma, using p44/42 MAPK (Erk1/2) (137F5) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded U-87MG cells, showing membrane localization, using PDGF Receptor β (28E1) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis using Akt (pan) (C67E7) Rabbit mAb on SignalSlide (TM) Phospho-Akt (Ser473) IHC Controls #8101 (paraffin-embedded LNCaP cells, untreated (left) or LY294002-treated (right)).


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human lung carcinoma, untreated (left) or λ phosphatase-treated (right), using Phospho-p44/42 MAPK (Erk1/2) (Thr202/Tyr204) (D13.14.4E) XP® Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human breast carcinoma using Phospho-Akt (Ser473) (D9E) XP® Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human colon carcinoma using SHP-2 (D50F2) Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human breast carcinoma, using p44/42 MAPK (Erk1/2) (137F5) Rabbit mAb in the presence of control peptide (left) or #1240 p44/42 MAPK (Erk1/2) Blocking Peptide (#4695 Specific) (right).

Flow Cytometry

Flow Cytometry

Flow cytometric analysis of Jurkat cells using Akt (pan) (C67E7) Rabbit mAb (blue) compared to a nonspecific negative control antibody (red).

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis using Phospho-p44/42 MAPK (Erk1/2) (Thr202/Tyr204) (D13.14.4E) XP® Rabbit mAb on SignalSlide™ Phospho-p44/42 MAPK (Thr202/Tyr204) IHC Controls #8103 (paraffin-embedded NIH/3T3 cells, treated with U0126 #9903 (left) or TPA #4174 (right).


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis using Phospho-Akt (Ser473) (D9E) XP® Rabbit mAb on SignalSlide® Phospho-Akt (Ser473) IHC Controls #8101 (paraffin-embedded LNCaP cells, untreated (left) or LY294002-treated (right)).

IHC-F (frozen)

IHC-F (frozen)

Immunohistochemical analysis of frozen U-87MG xenograft using PDGF Receptor beta (28E1) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human melanoma using using SHP-2 (D50F2) Rabbit mAb.


Flow Cytometry

Flow Cytometry

Flow cytometric analysis of Jurkat cells, U0126-treated (blue) or PMA-treated (green), using p44/42 MAPK (Erk1/2) (137F5) Rabbit mAb compared to a nonspecific negative control antibody (red).

IF-IC

IF-IC

Confocal immunofluorescent analysis of NIH/3T3 cells, serum-starved (left) or PDGF-treated (right), using PDGF Receptor beta (28E1) Rabbit mAb (green). Blue pseudocolor = DRAQ5® #4084 (fluorescent DNA dye).

IF-IC

IF-IC

Confocal immunofluorescent analysis of C2C12 cells, LY294002-treated (left) or insulin-treated (right), using Akt (pan) (C67E7) Rabbit mAb (green). Actin filaments have been labeled with Alexa Fluor® 555 phalloidin (red). Blue pseudocolor = DRAQ5™ (fluorescent DNA dye).


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human lung carcinoma using Phospho-Akt (Ser473) (D9E) XP® Rabbit mAb.

Flow Cytometry

Flow Cytometry

Flow cytometric analysis of Jurkat cells, treated with U0126 (10 µM, 2 hrs; green) or treated with TPA #4174 (200 nM, 30 min; blue) using Phospho-p44/42 MAPK (Erk1/2) (Thr202/Tyr204) (D13.14.4E) XP® Rabbit mAb (solid lines) or concentration-matched Rabbit (DA1E) mAb IgG XP® Isotype Control #3900 (dashed lines). Anti-rabbit IgG (H+L), F(ab')2 Fragment (Alexa Fluor® 488 Conjugate) #4412 was used as a secondary antibody.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse ovary using SHP-2 (D50F2) Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded PTEN heterozygous mutant mouse endometrium using Phospho-Akt (Ser473) (D9E) XP® Rabbit mAb. (Tissue section courtesy of Dr. Sabina Signoretti, Brigham and Women's Hospital, Harvard Medical School, Boston, MA.)

IF-IC

IF-IC

Confocal immunofluorescent analysis of Drosophila egg chambers, untreated (top) or λ phosphatase-treated (bottom), using Phospho-p44/42 MAPK (Erk1/2) (Thr202/Tyr204) (D13.14.4E) XP® Rabbit mAb #4370 (green) and S6 Ribosomal Protein (54D2) Mouse mAb #2317 (red). Blue pseudocolor = DRAQ5® #4084 (fluorescent DNA dye).

IF-IC

IF-IC

Confocal immunofluorescent analysis of NIH/3T3 cells, treated with either U0126 (MEK1/2 Inhibitor) #9903 (left) or PDGF (right), using p44/42 MAPK (Erk1/2) (137F5) Rabbit mAb (green). Actin filaments have been labeled with DY-554 phalloidin (red).


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human endometrioid adenocarcinoma using SHP-2 (D50F2) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded U-87MG xenograft, untreated (left) or lambda phosphatase-treated (right), using Phospho-Akt (Ser473) (D9E) XP® Rabbit mAb.

IF-IC

IF-IC

Confocal immunofluorescent analysis of HT1080 cells, starved overnight then treated with U0126 #9903 (10 uM, 2 h; left) or PDBu (Phorbol 12,13-Dibutyrate) #12808 (100 nM, 15 m; right) using Phospho-p44/42 MAPK (Erk1/2) (Thr202/Tyr204) (D13.14.4E) XP® Rabbit mAb #4370 (green) and β-Actin (8H10D10) Mouse mAb #3700 (red). Blue pseudocolor = DRAQ5® #4084 (fluorescent DNA dye).


Flow Cytometry

Flow Cytometry

Flow cytometric analysis of Jurkat cells, untreated (green) or treated with LY294002 #9901, wortmannin #9951 and U0126 #9903 (blue), using Phospho-Akt (Ser473) (D9E) XP® Rabbit mAb compared to a nonspecific negative control antibody (red).

IF-IC

IF-IC

Confocal immunofluorescent analysis of C2C12 cells, LY294002-treated (left) or insulin-treated (right), using Phospho-Akt (Ser473) (D9E) XP® Rabbit mAb (green). Actin filaments have been labeled with Alexa Fluor® 555 phalloidin #8953 (red). Blue pseudocolor = DRAQ5®#4084 (fluorescent DNA dye).

バックグラウンド

Platelet derived growth factor (PDGF) family proteins form dimers (PDGF AA, PDGF AB, PDGF BB, PDGF CC, and PDGF DD) that bind receptor tyrosine kinases PDGF receptor α (PDGFRα) and PDGF receptor β (PDGFRβ) in a specific pattern. PDGFRβ homodimers bind PDGF BB and DD homodimers and the PDGF AB heterodimer. Heteromeric receptor PDGF α/β binds PDGF B, C, and D homodimers and the PDGF AB heterodimer (1). Ligand binding induces PDGF receptor dimerization and autophosphorylation, followed by binding and activation of cytoplasmic SH2 domain-containing signal transduction molecules, such as GRB2, Src, GAP, PI3 kinase, PLCγ, and NCK. Activated PDGF receptors initiate signaling pathways that control cell growth, actin reorganization, migration, and differentiation (2). PDGFRβ kinase-insert region residue Tyr751 forms the PI3 kinase docking site, and phosphorylation of PDGFRβ at this site inhibits the association between the SH2 domain of the PI3 kinase p85 subunit and PDGFRβ (3,4).

SHP-2 (PTPN11) is a nonreceptor protein tyrosine phosphatase that participates in signaling pathways that control cell growth, differentiation, migration, and death (5). Activation of SHP-2 and its association with Gab1 is critical for sustained Erk activation downstream of growth factor receptors and cytokines (6). Phosphorylation of SHP-2 at Tyr542 and Tyr580 in response to growth factor receptor activation is thought to relieve basal inhibition and stimulate SHP-2 tyrosine phosphatase activity (7,8).

Insulin and various growth/survival factors activate Akt, a kinase that acts in a wortmannin-sensitive pathway involving PI3 kinase to help control survival and apoptosis (9-11). Akt is activated by phospholipid binding and activation loop phosphorylation at Thr308 by PDK1 (12) and by phosphorylation within the carboxy terminus at Ser473.

The p44/42 MAPK (Erk1/2) signaling pathway is activated in response to extracellular stimuli including mitogens, growth factors, and cytokines (13-15). Research suggests that this pathway is an important target in cancer diagnosis and treatment (16). External stimuli lead to activation of a kinase cascade that results in the activation of p44 and p42 by a MAP kinase. MEK1 and MEK2 activate p44 and p42 through phosphorylation of activation loop residues Thr202/Tyr204 and Thr185/Tyr187, respectively.

Clinical studies describe PDGF expression in a number of different solid tumors, from glioblastomas to prostate carcinomas. The biological role of PDGF signaling in these tumors varies from autocrine stimulation of cancer cell growth to more subtle paracrine interactions involving adjacent stroma and even angiogenesis. Targeting PDGF signaling may be an effective way for tumor treatment (17).

使用例
製品をご使用いただいて研究を発表されましたら、ぜひお知らせください

関連製品
12630   SignalFire™ Plus ECL Reagent
12757   SignalFire™ Elite ECL Reagent
6883   SignalFire™ ECL Reagent
7074   Anti-rabbit IgG, HRP-linked Antibody
7075   Anti-biotin, HRP-linked Antibody
7722   Blue Loading Buffer Pack
7723   Red Loading Buffer Pack
7727   Biotinylated Protein Ladder Detection Pack
9997   Tris Buffered Saline with Tween® 20 (TBST-10X)
9999   Nonfat Dry Milk

DRAQ5 is a registered trademark of Biostatus Limited.
SignalStain is a trademark of Cell Signaling Technology, Inc.
XP is a registered trademark of Cell Signaling Technology, Inc.
Alexa Fluor is a registered trademark of Life Technologies Corporation.
LumiGLO is a registered trademark of Kirkegaard & Perry Laboratories.
Cell Signaling Technology is a trademark of Cell Signaling Technology, Inc.
U.S. Patent No. 7,429,487, foreign equivalents, and child patents deriving therefrom.

本製品は試験研究用です。
