#14541 T Cell Signaling Antibody Sampler Kit

CSTコード 包装
希望納入価格 (円)
国内在庫 i
2019年3月20日11時40分 現在
ご登録代理店情報 i
カスタマー情報にご登録いただいた代理店を表示しています。
ご登録代理店の変更はこちら
#14541T1 Kit107,000
ログインすると国内在庫状況がご確認いただけます。

T Cell 製品一覧

14541 の推奨プロトコール i

最適な結果を得るために:Cell Signaling Technology (CST) 社は、各製品の推奨プロトコールを使用することを強くお薦めいたします。
推奨プロトコールはCST社内試験の徹底的なバリデーションに基づいて作成されておりますので、正確かつ再現性の高い結果が得られます。

注:各製品に最適化されたプロトコールをリンクしています。


キット内容 容量 用途 種交差性 ホモロジー† 検出分子量 アイソタイプ
CD3ε (CD3-12) Rat mAb #4443 20 µl WB, IP H, M Pg 21 Rat IgG1
Phospho-LAT (Tyr191) Antibody #3584 20 µl WB, IP H 36, 38 Rabbit
Phospho-Lck (Tyr505) Antibody #2751 20 µl WB, IP H, M 56 Rabbit
Phospho-PLCγ1 (Tyr783) (D6M9S) Rabbit mAb #14008 20 µl WB, IP, F H, M R, X, B, Dg 155 Rabbit IgG
Phospho-Src Family (Tyr416) (D49G4) Rabbit mAb #6943 20 µl WB, IP H, M, R, Mk 60 Rabbit IgG
Phospho-SLP-76 (Ser376) (D9D6E) Rabbit mAb #14745 20 µl WB H, M 76 Rabbit IgG
Phospho-Zap-70 (Tyr319)/Syk (Tyr352) (65E4) Rabbit mAb #2717 20 µl WB, IF-IC, F H, M R, Hm, C, B, Dg, Pg, Hr 70, 72 Rabbit IgG
Phospho-Zap-70 (Tyr493)/Syk (Tyr526) Antibody #2704 20 µl WB, IP H M, R 70 Rabbit
Anti-rat IgG, HRP-linked Antibody #7077 100 µl WB Goat
Anti-rabbit IgG, HRP-linked Antibody #7074 100 µl WB Goat

†Species predicted to react based on 100% sequence homology.

Applications Key: W=Western Blotting, IP=Immunoprecipitation, F=Flow Cytometry, IF-IC=Immunofluorescence (Immunocytochemistry)
Reactivity Key: H=Human, M=Mouse, R=Rat, Mk=Monkey

貯法
-20℃
社内データ

Western Blotting

Western Blotting

Western blot analysis of extracts from Jurkat cells (starved for 16 hours) treated with calf intestinal alkaline phosphatase (CIP) or H2O2 (2 mM), using Phospho-Lck (Tyr505) Antibody (upper) or control Lck Antibody #2752 (lower).

Western Blotting

Western Blotting

After the primary antibody is bound to the target protein, a complex with HRP-linked secondary antibody is formed. The LumiGLO® is added and emits light during enzyme catalyzed decomposition.

Western Blotting

Western Blotting

Western blot analysis of SDS extracts from untreated or anti-CD3 treated (10 µg/ml for 2 minutes) human Jurkat cells after overnight serum starvation using Phospho-LAT (Tyr191) Antibody.


Western Blotting

Western Blotting

Western blot analysis of extracts from Jurkat cells treated with hydrogen peroxide (2mM for 2 minutes) or with lambda phosphatase and extracts from Ramos cells treated with anti-human IgM (12 micrograms/ml for 2 minutes) using Phospho-Zap-70 (Tyr319)/Syk (Tyr352) (65E4) Rabbit mAb.

Western Blotting

Western Blotting

After the primary antibody is bound to the target protein, a complex with HRP-linked secondary antibody is formed. The LumiGlo® is added and emits light during enzyme catalyzed decomposition.

Western Blotting

Western Blotting

Western blot analysis of total cell lysates from DND41 and Molt4 cells using CD3ε (CD3-12) Rat mAb.


Western Blotting

Western Blotting

Western blot analysis of extracts NIH/3T3 cells, serum-starved or treated with human Platelet-Derived Growth Factor BB hPDGF-BB #8912 (100 ng/ml, 15 min), using Phospho-Src Family (Tyr416) (D49G4) Rabbit mAb (upper) or Src (36D10) Rabbit mAb #2109 (lower).

Western Blotting

Western Blotting

Western blot analysis of extracts from Ramos cells untreated or treated with 10 µg/ml IgM for 2 minutes with or without calf intestinal phosphatase (CIP), using Phospho-Zap-70 (Tyr493)/Syk (Tyr526) Antibody (upper) or Syk Antibody #12358 (lower).

Western Blotting

Western Blotting

Western blot analysis of extracts from NIH/3T3 cells, untreated (-) or stimulated with hPDGF-BB #8912 (5 min; +), and from A-431 cells, untreated (-) or stimulated with hEGF #8916 (5 min; +), using Phospho-PLCγ1 (Tyr783) (D6M9S) Rabbit mAb (upper) and β-Actin (D6A8) Rabbit mAb #8457 (lower).


Western Blotting

Western Blotting

Western blot analysis of extracts from Jurkat cells, untreated (-) or treated with H2O2 (11 mM, 1 min; +), using Phospho-SLP-76 (Ser376) (D9D6E) Rabbit mAb (upper) or SLP-76 Antibody #4958 (lower).

Western Blotting

Western Blotting

Western blot analysis of extracts from Jurkat cells starved for 16 hours and treated with 2 mM H2O2 for 3 minutes, using Phospho-Zap-70 (Tyr493)/Syk (Tyr526) Antibody (upper) or control Zap-70 Antibody #2702 (lower).

IP

IP

Immunoprecipitation of phospho-PLCγ1 (Tyr783) from A-431 cell extracts stimulated with hEGF #8916 using Rabbit (DA1E) mAb IgG XP® Isotype Control #3900 (lane 2) or Phospho-PLCγ1 (Tyr783) (D6M9S) Rabbit mAb (lane 3). Lane 1 is 10% input. Western blot analysis was performed using Phospho-PLCγ1 (Tyr783) (D6M9S) Rabbit mAb.


Flow Cytometry

Flow Cytometry

Flow cytometric analysis of Ramos cells, untreated (blue) or treated with anti-IgM (green), using Phospho-Zap-70 (Tyr319)/Syk (Tyr352) (65E4) Rabbit mAb. Anti-rabbit IgG (H+L), F(ab')2 Fragment (PE Conjugate) #8885 was used as a secondary antibody.

Western Blotting

Western Blotting

Western blot analysis of extracts from EL4 cells, untreated (-) or treated with H2O2 (11 mM, 1 min; +), using Phospho-SLP-76 (Ser376) (D9D6E) Rabbit mAb (upper) or SLP-76 Antibody #4958 (lower).

Flow Cytometry

Flow Cytometry

Flow cytometric analysis of NIH/3T3 cells, untreated (blue) or treated with recombinant mouse PDGF-BB (200 ng/ml, 15 min; green), using Phospho-PLCγ1 (Tyr783) (D6M9S) Rabbit mAb. Anti-rabbit IgG (H+L), F(ab')2 Fragment (Alexa Fluor® 488 Conjugate) #4412 was used as a secondary antibody.


IF-IC

IF-IC

Confocal immunofluorescent analysis of Ramos cells, human IgM treated (left) or untreated (right), using Phospho-Zap-70 (Tyr319)/Syk (Tyr352) (65E4) Rabbit mAb (green). Red = Propidium Iodide (PI)/RNase Staining Solution #4087.

バックグラウンド

When T cells encounter antigens via the T cell receptor (TCR), information about the quantity and quality of antigens is relayed to the intracellular signal transduction machinery (1). This activation process depends mainly on CD3 (Cluster of Differentiation 3), a multiunit protein complex that directly associates with the TCR α and ß chains. CD3 is composed of four polypeptides: ζ, γ, ε and δ. Each of these polypeptides contains at least one immunoreceptor tyrosine-based activation motif (ITAM) (2). The Src family kinases Lck and Fyn are recruited to the TCR complex upon stimulation and activate the downstream tyrosine kinases to initiate signaling. Phosphorylation of Lck at Tyr394 leads to an increase in Lck activity while phosphorylation of Tyr505 in the Lck carboxy-terminal tail down-regulates Lck catalytic activity (3). Zap-70 and Syk are rapidly phosphorylated on several tyrosine residues through autophosphorylation and transphosphorylation by Src family tyrosine kinases.  Activation loop phosphorylation of Zap-70 at Tyr493 and Syk at Tyr526 leads to complete activation of both kinases (4).  Subsequent phosphorylation of other tyrosine residues within the kinase interdomain B region, including Zap-70 at Tyr315 and Zap-70 at Tyr 319, create docking sites for downstream signaling molecules.  Zap-70 and Syk phosphorylate the transmembrane adaptor protein LAT at multiple, conserved tyrosine residues within SH2 binding motifs, exposing these motifs as docking sites for downstream signaling targets (5,6). The phosphorylation of LAT at Tyr171 and Tyr191 enables the binding of Grb2, Gads/SLP-76, PLCγ1, and PI3 kinase. The adapter protein SLP-76 is phosphorylated at Tyr113 and Tyr128, allowing for binding of the Grb2-like adapter Gads.  Phosphorylation of SLP-76 at Ser376 by hematopoietic progenitor kinase 1 (HPK1) induces interaction with 14-3-3ε and down-regulates TCR signaling (7,8).  Phosphoinositide-specific phospholipase PLCγ1 enzyme activity is also stimulated by Zap-70 and Syk phosphorylation on Tyr783, Tyr711, and Tyr1253, resulting in robust PI-4,5-P2 hydrolysis (9).

使用例
製品をご使用いただいて研究を発表されましたら、ぜひお知らせください

関連製品
7074   Anti-rabbit IgG, HRP-linked Antibody
7077   Anti-rat IgG, HRP-linked Antibody

DRAQ5 is a registered trademark of Biostatus Limited.
Tween is a registered trademark of ICI Americas, Inc.
XP is a registered trademark of Cell Signaling Technology, Inc.
Alexa Fluor is a registered trademark of Life Technologies Corporation.
LumiGLO is a registered trademark of Kirkegaard & Perry Laboratories.
Cell Signaling Technology is a trademark of Cell Signaling Technology, Inc.
U.S. Patent No. 7,429,487, foreign equivalents, and child patents deriving therefrom.

本製品は試験研究用です。
