#37495 Mouse Immune Cell Phenotyping IHC Antibody Sampler Kit


CSTコード 包装
希望納入価格 (円)
国内在庫 i
2019年3月20日11時40分 現在
ご登録代理店情報 i
カスタマー情報にご登録いただいた代理店を表示しています。
ご登録代理店の変更はこちら
#37495T1 Kit116,000
ログインすると国内在庫状況がご確認いただけます。
37495 の推奨プロトコール i

最適な結果を得るために:Cell Signaling Technology (CST) 社は、各製品の推奨プロトコールを使用することを強くお薦めいたします。
推奨プロトコールはCST社内試験の徹底的なバリデーションに基づいて作成されておりますので、正確かつ再現性の高い結果が得られます。

注:各製品に最適化されたプロトコールをリンクしています。


キット内容 容量 用途 種交差性 ホモロジー† 検出分子量 アイソタイプ
CD3ε (D4V8L) Rabbit mAb #99940 20 µl WB, IHC-Bond, IHC-P M 22 Rabbit IgG
CD4 (D7D2Z) Rabbit mAb #25229 20 µl WB, IHC-Bond, IHC-P M, R 55 Rabbit IgG
CD8α (D4W2Z) XP® Rabbit mAb (Mouse Specific) #98941 20 µl WB, IHC-Bond, IHC-P M 35-42 Rabbit IgG
FoxP3 (D6O8R) Rabbit mAb #12653 20 µl IHC-Bond, IHC-P, IF-F, F M Rabbit IgG
F4/80 (D2S9R) XP® Rabbit mAb #70076 20 µl WB, IP, IHC-P M 65-250 Rabbit IgG
CD19 (D4V4B) XP® Rabbit mAb #90176 20 µl WB, IP, IHC-Bond, IHC-P H, M B 95 Rabbit IgG
CD11c (D1V9Y) Rabbit mAb #97585 20 µl WB, IHC-Bond, IHC-P, IF-F, IF-IC M 145 Rabbit IgG
Granzyme B (D6E9W) Rabbit mAb #46890 20 µl WB, IHC-Bond, IHC-P H, M 30 Rabbit IgG

†Species predicted to react based on 100% sequence homology.

Applications Key: W=Western Blotting, IHC-Bond=IHC-Leica® Bond™, IHC-P=Immunohistochemistry (Paraffin), IF-F=Immunofluorescence (Frozen), F=Flow Cytometry, IP=Immunoprecipitation, IF-IC=Immunofluorescence (Immunocytochemistry)
Reactivity Key: M=Mouse, R=Rat, H=Human

特異性・感度
Each antibody included in the Mouse Immune Cell Phenotyping IHC Antibody Sampler Kit recognizes endogenous levels of its target mouse protein. Non-specific staining has been observed in mouse pancreas with CD3ε (D4V8L) Rabbit mAb, in mouse kidney and liver with CD4 (D7D2Z) Rabbit mAb, and in the sweat glands with Granzyme B (D6E9W) Rabbit mAb.
使用抗原
Monoclonal antibodies are produced by immunizing animals with synthetic peptides corresponding to residues surrounding Val31 of mouse CD3ε protein, Asp42 of mouse CD8α protein, Ala232 of mouse CD4 protein, Pro44 of mouse FoxP3 protein, Leu427 of human CD19 protein, Ala1153 of mouse CD11c protein, or with recombinant proteins specific to human Granzyme B protein or mouse F4/80 protein.

ホモロジー (相同性) 検索をご希望の場合 >>>

ホモロジー検索をご要望の際は、ご希望のサンプル種のアミノ酸配列とともにお問合せください。

貯法
-20℃
社内データ

Western Blotting

Western Blotting

Western blot analysis of extracts from mouse CD8+ T cells, mouse spleen, EL4 cells, and Raw264.7 cells using CD8α (D4W2Z) XP® Rabbit mAb (Mouse Specific) (upper), and β-Actin (D6A8) Rabbit mAb #8457 (lower).

Western Blotting

Western Blotting

Western blot analysis of extracts from mouse spleen, EL4 cells, and Raji cells using CD3ε (D4V8L) Rabbit mAb (upper) and β-Actin (D6A8) Rabbit mAb #8457 (lower).

Western Blotting

Western Blotting

Western blot analysis of extracts from various cell lines and tissues using CD4 (D7D2Z) Rabbit mAb (upper) and β-Actin (D6A8) Rabbit mAb #8457 (lower).


IF-F

IF-F

Immunofluorescent analysis of mouse spleen using FoxP3 (D6O8R) Rabbit mAb (red) and a CD4 antibody (green). Blue = DRAQ5® #4084 (fluorescent DNA dye).

Note: FoxP3 (D6O8R) Rabbit mAb has been validated on freshly-prepared frozen tissue sections that were fixed for 15 minutes in 4% formaldehyde. Over-fixation diminishes the performance of this antibody.

IHC-Leica® Bond™

IHC-Leica® Bond™

Immunohistochemical analysis of paraffin-embedded mouse small intestine using CD3ε (D4V8L) Rabbit mAb performed on the Leica® BOND™ Rx.

IHC-Leica® Bond™

IHC-Leica® Bond™

Immunohistochemical analysis of paraffin-embedded mouse lung using CD8α (D4W2Z) XP® Rabbit mAb (Mouse Specific) performed on the Leica® BOND™ Rx.


Western Blotting

Western Blotting

Western blot analysis of extracts from various cell lines using F4/80 (D2S9R) XP® Rabbit mAb (upper) or β-Actin (D6A8) Rabbit mAb #8457 (lower).

IHC-Leica® Bond™

IHC-Leica® Bond™

Immunohistochemical analysis of paraffin-embedded 4T1 metastatic tumor in mouse lung using CD4 (D7D2Z) Rabbit mAb performed on the Leica® BOND™ Rx.

IHC-Leica® Bond™

IHC-Leica® Bond™

Immunohistochemical analysis of paraffin-embedded 4T1 metastatic tumor in mouse lung using FoxP3 (D6O8R) Rabbit mAb performed on the Leica® BOND™ Rx.


Western Blotting

Western Blotting

Western blot analysis of extracts from various cell lines using CD19 (D4V4B) XP® Rabbit mAb (upper) and β-Actin (D6A8) Rabbit mAb #8457 (lower). As expected, CD19 protein is not detected in either U-937 cells or Raw 264.7 cells.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse liver using F4/80 (D2S9R) XP® Rabbit mAb.

IHC-Leica® Bond™

IHC-Leica® Bond™

Immunohistochemical analysis of paraffin-embedded human endometrioid carcinoma using CD19 (D4V4B) XP® Rabbit mAb performed on the Leica® Bond™ Rx.


IHC-Leica® Bond™

IHC-Leica® Bond™

Immunohistochemical analysis of paraffin-embedded 4T1 mammary tumor using CD11c (D1V9Y) Rabbit mAb performed on the Leica® Bond™ Rx.

Western Blotting

Western Blotting

Western blot analysis of extracts from Raw 264.7, C2C12, and 3T3 cells using CD11c (D1V9Y) Rabbit mAb (upper) or β-Actin (D6A8) Rabbit mAb #8457 (lower).

IHC-Leica® Bond™

IHC-Leica® Bond™

Immunohistochemical analysis of paraffin-embedded human colon adenocarinoma using Granzyme B (D6E9W) Rabbit mAb performed on the Leica® BOND™ Rx.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse spleen using CD8α (D4W2Z) XP® Rabbit mAb (Mouse Specific).

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse thymus using FoxP3 (D6O8R) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse colon using CD4 (D7D2Z) Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse spleen using CD3ε (D4V8L) Rabbit mAb.

Western Blotting

Western Blotting

Western blot analysis of extracts from Daudi cells, untreated (-) or treated with PNGase F (+), using CD19 (D4V4B) XP® Rabbit mAb (upper) and β-Actin (D6A8) Rabbit mAb #8457 (lower).

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse spleen using F4/80 (D2S9R) XP® Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse kidney using CD11c (D1V9Y) Rabbit mAb.

IHC-Leica® Bond™

IHC-Leica® Bond™

Immunohistochemical analysis of paraffin-embedded CT26.WT syngeneic tumor using Granzyme B (D6E9W) Rabbit mAb performed on the Leica® BOND™ Rx.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse small intestine using CD8α (D4W2Z) XP® Rabbit mAb (Mouse Specific).


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse spleen using FoxP3 (D6O8R) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse small intestine using CD3ε (D4V8L) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse small intestine using CD4 (D7D2Z) Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human colon carcinoma using CD19 (D4V4B) XP® Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse small intestine using F4/80 (D2S9R) XP® Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse liver using CD11c (D1V9Y) Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human papillary carcinoma of the breast using Granzyme B (D6E9W) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse lung using CD3ε (D4V8L) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse small intestine using FoxP3 (D6O8R) Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse spleen using CD4 (D7D2Z) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded Raw 264.7 cell pellet (left, positive) or Neuro-2A cell pellet (right, negative) using F4/80 (D2S9R) XP® Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human lung carcinoma using CD19 (D4V4B) XP® Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse lung using CD11c (D1V9Y) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse 4T1 mammary tumor using Granzyme B (D6E9W) Rabbit mAb.

Flow Cytometry

Flow Cytometry

Flow cytometric analysis of murine spleen lymphocytes using a CD25 antibody and FoxP3 (D6O8R) Rabbit mAb. Anti-rabbit IgG (H+L), (F(ab')2 ) Fragment (Alexa Fluor® 488 Conjugate) #4412 was used as a secondary antibody. Analysis was performed on a gated CD4+ T cell population.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded rat lung using CD4 (D7D2Z) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse lung using FoxP3 (D6O8R) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human lymphoma using CD19 (D4V4B) XP® Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded Raw 264.7 cell pellet (left, positive) or C2C12 cell pellet (right, negative) using CD11c (D1V9Y) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded KARPAS-299 cell pellet (left, positive) or Jurkat cell pellet (right, negative) using Granzyme B (D6E9W) Rabbit mAb. KARPAS cell line source: Dr. Abraham Karpas at the University of Cambridge.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human colon carcinoma using Granzyme B (D6E9W) Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Multiplex immunohistochemical analysis of paraffin-embedded mouse LL2 syngeneic tumor tissue using CD3ε (D4V8L) rabbit mAb (red), F4/80 (D2S9R) XP® rabbit mAb #70076 (orange), PD-1 (D7D5W) XP® rabbit mAb #84651 (green), PD-L1 (D5V3B) rabbit mAb #64988 (yellow), CD8α (D4W2Z) XP® rabbit mAb #98941 (magenta) and pan keratin (C11) mouse mAb #4279 (cyan).

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse spleen using CD19 (D4V4B) XP® Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded mouse spleen using CD11c (D1V9Y) Rabbit mAb.


Western Blotting

Western Blotting

Western blot analysis of extracts from various human cells using Granzyme B (D6E9W) Rabbit mAb (upper) and β-actin (D6A8) Rabbit mAb #8457 (lower). CD8+ T cells were purified from human blood and stimulated for 9 days using beads coated with CD3 and CD28 antibodies in the presence of human interleukin-2 (hIL-2) #8907 (20 ng/ml). KARPAS cell line source: Dr. Abraham Karpas at the University of Cambridge.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human tonsil using CD19 (D4V4B) XP® Rabbit mAb.

Western Blotting

Western Blotting

Western blot analysis of extracts from CTLL-2, mouse CD8+ T, and C2C12 cells using Granzyme B (D6E9W) Rabbit mAb (upper) and β-actin (D6A8) Rabbit mAb #8457 (lower). CD8+ T cells were purified from mouse spleens and stimulated for 9 days using beads coated with mouse CD3 and CD28 antibodies in the presence of Mouse Interleukin-2 (mIL-2) #5201 (20 ng/ml).


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human non-Hodgkin's lymphoma using Granzyme B (D6E9W) Rabbit mAb.

IF-IC

IF-IC

Confocal immunofluorescent analysis of Raw 264.7 cells (left, positive) and 3T3 cells (right, negative) using CD11c (D1V9Y) Rabbit mAb (green). Red = Propidium Iodide (PI)/RNase Staining Solution #4087.

IF-F

IF-F

Confocal immunofluorescent analysis of mouse spleen (left) and mouse kidney (right) using CD11c (D1V9Y) Rabbit mAb. Nuclei were labeled with ProLong® Gold Antifade reagent with DAPI #8961 (blue).


バックグラウンド

Cluster of Differentiation 3 (CD3) is a multiunit protein complex expressed on the surface of T-cells that directly associates with the T-cell receptor (TCR). CD3 is composed of four polypeptides: ζ, γ, ε and δ. Engagement of TCR complex with antigens presented in Major Histocompatibility Complexes (MHC) induces tyrosine phosphorylation in the immunoreceptor tyrosine-based activation motif (ITAM) of CD3 proteins. CD3 phosphorylation is required for downstream signaling through ZAP-70 and p85 subunit of PI-3 kinase, leading to T cell activation, proliferation, and effector functions (1). Cluster of Differentiation 8 (CD8) is a transmembrane glycoprotein expressed primarily on cytotoxic T cells, but has also been described on a subset of dendritic cells in mice (2,3). On T cells, CD8 is a co-receptor for the TCR, and these two distinct structures are required to recognize antigen bound to MHC Class I (2). Cluster of Differentiation 4 (CD4) is expressed on the surface of T helper cells, regulatory T cells, monocytes, macrophages, and dendritic cells, and plays an important role in the development and activation of T cells. On T cells, CD4 is the co-receptor for the TCR, and these two distinct structures recognize antigen bound to MHC Class II. CD8 and CD4 co-receptors ensure specificity of the TCR–antigen interaction, prolong the contact between the T cell and the antigen presenting cell, and recruit the tyrosine kinase Lck, which is essential for T cell activation (2). Granzyme B is a serine protease expressed by CD8+ cytotoxic T lymphocytes and natural killer (NK) cells and is a key component of the immune response to pathogens and transformed cancer cells (4). Forkhead box P3 (FoxP3) is crucial for the development of T cells with immunosuppressive regulatory properties and is a well-established marker for T regulatory cells (Tregs) (5). CD19 is a co-receptor expressed on B cells that amplifies the signaling cascade initiated by the B cell receptor (BCR) to induce activation. It is a biomarker of B lymphocyte development, lymphoma diagnosis, and can be utilized as a target for leukemia immunotherapies (6,7). F4/80 (EMR1) is a heavily glycosylated G-protein-coupled receptor and is a well-established marker for mouse macrophages (8). CD11c (integrin αX, ITGAX) is a transmembrane glycoprotein highly expressed by dendritic cells, and has also been observed on activated NK cells, subsets of B and T cells, monocytes, granulocytes, and some B cell malignancies including hairy cell leukemia (9,10).
