#86163 PD-1 (D4W2J) XP® Rabbit mAb

Shopping Days対象製品 対象製品の中から、まとめて購入で一部製品が無料に!
*ウェブで専用注文書を作成し、代理店へご注文ください。

をクリックすると選べます。

CSTコード 包装
希望納入価格 (円)
Shopping Daysで購入
国内在庫 i
2019年1月18日15時10分 現在
ご登録代理店情報 i
カスタマー情報にご登録いただいた代理店を表示しています。
ご登録代理店の変更はこちら
#86163S100 μL138,000
ログインすると国内在庫状況がご確認いただけます。
#86163T20 μL49,000

PDCD1 製品一覧 | #86163 が入っているAntibody Sampler キット一覧

感度分子量 (kDa)抗体の由来貯法
内在性52-65Rabbit -20℃
種交差性 (社内試験済)
交差する可能性がある種 i

社内試験はしていませんが、配列が100%相同であるため反応すると推定される種

ヒト -
86163 の推奨プロトコール i

最適な結果を得るために:Cell Signaling Technology (CST) 社は、各製品の推奨プロトコールを使用することを強くお薦めいたします。
推奨プロトコールはCST社内試験の徹底的なバリデーションに基づいて作成されておりますので、正確かつ再現性の高い結果が得られます。

注:各製品に最適化されたプロトコールをリンクしています。



ウェスタンブロッティング (1:1000)免疫沈降 (1:200)免疫組織染色 (パラフィン) (1:200)フローサイトメトリー (1:100)Immunohistochemistry (Leica® Bond™) (1:200)

下記ステップについては、データシートの右側もあわせてご参照ください。

IHC-P: 抗体希釈液 / 抗原賦活化

CST推奨プロトコールに欠かせない関連製品

特異性・感度
内在性レベルのPD-1 タンパク質を検出します。
使用抗原
ヒトのPD-1 タンパク質のAla274 周辺領域 (合成ペプチド)

ホモロジー (相同性) 検索をご希望の場合 >>>

ホモロジー検索をご要望の際は、ご希望のサンプル種のアミノ酸配列とともにお問合せください。

社内データ

※下記の社内データは、すべて86163 の推奨プロトコールで実験した結果です。

Western Blotting

Western Blotting

Western blot analysis of extracts from human CD4+ T cells, MOLT-4, and Jurkat cells using PD-1 (D4W2J) XP® Rabbit mAb (upper), and β-Actin (D6A8) Rabbit mAb #8457 (lower). CD4+ T cells were purified from human blood and stimulated for 9 days using beads coated with CD3 and CD28 antibodies in the presence of human interleukin-2 (hIL-2) #8907 (6.7 ng/ml).

IP

IP

Immunoprecipitation of PD-1 protein from Molt-4 cell extracts. Lane 1 is 10% input, lane 2 is Rabbit (DA1E) mAb IgG XP® Isotype Control #3900, and lane 3 is PD-1 (D4W2J) XP® Rabbit mAb. Western blot analysis was performed using PD-1

(D4W2J) XP® Rabbit mAb.

IHC-Leica® Bond™

IHC-Leica® Bond™

Immunohistochemical analysis of paraffin-embedded human infiltrating papillary carcinoma of the breast using PD-1 (D4W2J) XP® Rabbit mAb performed on the Leica® BOND™ Rx.


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human colon carcinoma using PD-1 (D4W2J) XP® Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human B-cell non-Hodgkin's lymphoma using PD-1 (D4W2J) XP® Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded 293 cell pellets, control (left) or PD-1 transfected (right), using PD-1 (D4W2J) XP® Rabbit mAb.


IHC-P (paraffin)

IHC-P (paraffin)

Multiplex immunohistochemical analysis of paraffin-embedded human breast carcinoma usng PD-1 (D4W2J) XP® rabbit mAb (green), PD-L1 (E1L3N®) XP® rabbit mAb #13684 (red), LAG3 (D2G4O™) XP® rabbit mAb #15372 (magenta), TIM-3 (D5D5R™) XP® rabbit mAb #45208 (yellow), CD8α (C8/144B) mouse mAb #70306 (orange), and Pan-keratin (C11) mouse mAb #4545 (cyan).

IHC-P (paraffin)

IHC-P (paraffin)

Multiplex immunohistochemical analysis of paraffin-embedded human ovarian carcinoma using PD-1 (D4W2J) XP® rabbit mAb (green), B7-H3 (D9M2L) XP® rabbit mAb #14058 (red), B7-H4 (D1M8I) XP® rabbit mAb (cyan), LAG3 (D2G4O™) XP® rabbit mAb #15372 (magenta), TIM-3 (D5D5R™) XP® rabbit mAb #45208 (yellow), and VISTA (D1L2G™) XP® rabbit mAb #64953 (orange).

Flow Cytometry

Flow Cytometry

Flow cytometric analysis of human peripheral blood mononuclear cells, untreated (left column) or CD3/CD28-treated (72 hr; right column), using PD-1 (D4W2J) XP® Rabbit mAb #86163 (top row) or concentration-matched Rabbit (DA1E) mAb IgG XP® Isotype Control #3900 (bottom row), and co-stained with a CD3 antibody.  Anti-rabbit IgG (H+L), F(ab')2 Fragment (Alexa Fluor® 488 Conjugate) #4412 was used as a secondary antibody.


バックグラウンド

The programmed cell death 1 protein (PD-1, PDCD1, CD279) is a member of the CD28 family of immunoreceptors that regulate T cell activation and immune responses (1-3). The PD-1 protein contains an extracellular Ig V domain, a transmembrane domain, and a cytoplasmic tail that includes an immunoreceptor tyrosine-based inhibitory motif (ITIM) and an immunoreceptor tyrosine-based switch motif (ITSM). PD-1 is activated by the cell surface ligands PD-L1 and PD-L2 (4). Upon activation, PD-1 ITIM and ITSM phosphorylation leads to the recruitment of the protein tyrosine phosphatases SHP-1 and SHP-2, which suppress TCR signaling (5-7). In addition to activated T-cells, PD-1 is expressed in activated B-cells and monocytes, although its function in these cell types has not been fully characterized (8). The PD-1 pathway plays an important role in immune tolerance (3); however, research studies show that cancer cells often adopt this pathway to escape immune surveillance (9). Consequently, blockade of PD-1 and its ligands is proving to be a sound strategy for neoplastic intervention (10).

使用例

関連製品
12657   Plasminogen Antibody
12757   SignalFire™ Elite ECL Reagent
13079   Immunohistochemistry Application Solutions Kit (Rabbit)
13953   Prestained Protein Marker, Broad Range (11-190 kDa)
14166   Hematoxylin
14177   SignalStain® Mounting Medium
14746   SignalStain® Citrate Unmasking Solution (10X)
15019   Animal-Free Blocking Solution (5X)
6883   SignalFire™ ECL Reagent
7071   Phototope-HRP Western Blot Detection System, Anti-rabbit IgG, HRP-linked Antibody
7074   Anti-rabbit IgG, HRP-linked Antibody
7727   Biotinylated Protein Ladder Detection Pack
8059   SignalStain® DAB Substrate Kit
8112   SignalStain® Antibody Diluent
8114   SignalStain® Boost IHC Detection Reagent (HRP, Rabbit)
9997   Tris Buffered Saline with Tween® 20 (TBST-10X)
9999   Nonfat Dry Milk

BOND is a trademark of Leica Biosystems Melbourne Pty. Ltd. No affiliation or sponsorship between CST and Leica Microsystems IR GmbH or Leica Biosystems Melbourne Pty. Ltd is implied.
Tween is a registered trademark of ICI Americas, Inc.
SignalStain is a trademark of Cell Signaling Technology, Inc.
LEICA is a registered trade​mark of Leica Microsystems IR GmbH.
XP is a registered trademark of Cell Signaling Technology, Inc.
Alexa Fluor is a registered trademark of Life Technologies Corporation.
Cell Signaling Technology is a trademark of Cell Signaling Technology, Inc.

本製品は試験研究用です。
