#9936 NF-κB Pathway Sampler Kit

CSTコード 包装
希望納入価格 (円)
国内在庫 i
2019年1月17日15時10分 現在
ご登録代理店情報 i
カスタマー情報にご登録いただいた代理店を表示しています。
ご登録代理店の変更はこちら
#9936T1 Kit99,000
ログインすると国内在庫状況がご確認いただけます。

NF-kB 製品一覧

9936 の推奨プロトコール i

最適な結果を得るために:Cell Signaling Technology (CST) 社は、各製品の推奨プロトコールを使用することを強くお薦めいたします。
推奨プロトコールはCST社内試験の徹底的なバリデーションに基づいて作成されておりますので、正確かつ再現性の高い結果が得られます。

注:各製品に最適化されたプロトコールをリンクしています。


キット内容 容量 用途 種交差性 ホモロジー† 検出分子量 アイソタイプ
IKKα (3G12) Mouse mAb #11930 20 µl WB, IF-IC, F H, Mk 85 Mouse IgG1
IKKβ (D30C6) Rabbit mAb #8943 20 µl WB, IP H, M, R, Mk 87 Rabbit IgG
Phospho-IKKα/β (Ser176/180) (16A6) Rabbit mAb #2697 20 µl WB, IHC-P, IHC-F, F H, M, R, Mk B 85 IKK-alpha 87 IKK-beta Rabbit IgG
Phospho-NF-κB p65 (Ser536) (93H1) Rabbit mAb #3033 20 µl WB, IP, IF-IC, F H, M, R, Hm, Mk, Pg Dg 65 Rabbit IgG
IκBα (L35A5) Mouse mAb (Amino-terminal Antigen) #4814 20 µl WB, IP, IHC-P, IF-IC, F H, M, R, Mk, B, Pg 39 Mouse IgG1
Phospho-IκBα (Ser32) (14D4) Rabbit mAb #2859 20 µl WB, IP H, M, R, Mk C, B, Dg, Pg, GP 40 Rabbit IgG
NF-κB p65 (D14E12) XP® Rabbit mAb #8242 20 µl WB, IP, IHC-P, IF-IC, F, ChIP, ChIP-seq H, M, R, Hm, Mk, Dg 65 Rabbit IgG
Anti-rabbit IgG, HRP-linked Antibody #7074 100 µl WB Goat
Anti-mouse IgG, HRP-linked Antibody #7076 100 µl WB Horse

†Species predicted to react based on 100% sequence homology.

Applications Key: W=Western Blotting, IF-IC=Immunofluorescence (Immunocytochemistry), F=Flow Cytometry, IP=Immunoprecipitation, IHC-P=Immunohistochemistry (Paraffin), IHC-F=Immunohistochemistry (Frozen), ChIP=Chromatin IP, ChIP-seq=Chromatin IP-seq
Reactivity Key: H=Human, Mk=Monkey, M=Mouse, R=Rat, Hm=Hamster, Pg=Pig, B=Bovine, Dg=Dog

貯法
-20℃
※括弧付きの動物種は配列が100%相同であるため反応すると推定されます。
社内データ

Western Blotting

Western Blotting

After the primary antibody is bound to the target protein, a complex with HRP-linked secondary antibody is formed. The LumiGLO® is added and emits light during enzyme catalyzed decomposition.

Western Blotting

Western Blotting

Western blot analysis of extracts from HeLa and NIH/3T3 cells, untreated or TNF-α treated (#2169, 20 ng/ml for 5 minutes), using Phospho-NF-κB p65 (Ser536) (93H1) Rabbit mAb (upper) or NF-κB p65 Antibody #3034 (lower).

Western Blotting

Western Blotting

Western blot analysis of extracts from HeLa and NIH/3T3 cells, untreated or treated with TNF-α (#2169, 20 ng/ml) for 5 minutes, using Phospho-IκBα (Ser32) (14D4) Rabbit mAb (upper), or IκBα (44D4) Rabbit mAb #4812 (lower).


Western Blotting

Western Blotting

Western blot analysis of extracts from THP-1 cells, differentiated with TPA (#9905, 80 nM for 24h) and treated with 1 μg/ml LPS for the indicated times, using Phospho-IKKα/β (Ser176/180) (16A6) Rabbit mAb.

Western Blotting

Western Blotting

Western blot analysis of extracts from THP-1 cells, differentiated with TPA (#9905, 80 nM for 24h) and treated with 1 μg/ml LPS for the indicated times, using Phospho-IκBα (Ser32/36) (5A5) Mouse mAb #9246 (upper) and IκBα (L35A5) Mouse mAb (Amino-terminal Antigen) (lower).

Western Blotting

Western Blotting

Western blot analysis of extracts from various cell lines using NF-κB p65 (D14E12) XP® Rabbit mAb.


Flow Cytometry

Flow Cytometry

Flow cytometric analysis of HeLa cells using NF-κB p65 (D14E12) XP® Rabbit mAb (blue) compared to concentration matched Rabbit (DA1E) mAb IgG XP® Isotype Control #3900 (red).

Western Blotting

Western Blotting

Western blot analysis of extracts from various cell lines using IKKβ (D30C6) Rabbit mAb.

Western Blotting

Western Blotting

Western blot analysis of extracts from various cell lines using IKKα (3G12) Mouse mAb (upper) or β-Actin (D6A8) Rabbit mAb #8457 (lower).


Chromatin IP-seq

Chromatin IP-seq

Chromatin immunoprecipitations were performed with cross-linked chromatin from HeLa cells treated with hTNF-α #8902 (30 ng/ml, 1 hr) and NF-κB p65 (D14E12) XP® Rabbit mAb, using SimpleChIP® Enzymatic Chromatin IP Kit (Magnetic Beads) #9005. DNA Libraries were prepared using SimpleChIP® ChIP-seq DNA Library Prep Kit for Illumina® #56795. The figure shows binding across IL-8, a known target gene of NFκB (see additional figure containing ChIP-qPCR data). For additional ChIP-seq tracks, please download the product data sheet.

Western Blotting

Western Blotting

Western blot analysis of extracts from HeLa, NIH/3T3 and PC12 cells, using IkBα (L35A5) Mouse mAb (Amino-terminal Antigen).

Western Blotting

Western Blotting

Western blot analysis of extracts from TNF-alpha and Calyculin A treated HeLa and NIH/3T3 cells, using Phospho-IKKα/β (Ser176/180) (16A6) Rabbit mAb.


Western Blotting

Western Blotting

Western blot analysis of extracts from THP-1 cells, differentiated with TPA (#9905, 80 nM for 24h) and treated with 1 μg/ml LPS for the indicated times, using Phospho-NF-κB p65 (Ser536) (93H1) Rabbit mAb (upper) and NF-κB p65 (C22B4) Rabbit mAb #4764 (lower).

Chromatin IP

Chromatin IP

Chromatin immunoprecipitations were performed with cross-linked chromatin from HeLa cells treated with hTNF-α #8902 (30 ng/ml, 1 hr) and either NF-κB p65 (D14E12) XP® Rabbit mAb or Normal Rabbit IgG #2729 using SimpleChIP® Enzymatic Chromatin IP Kit (Magnetic Beads) #9003. The enriched DNA was quantified by Real-Time PCR using SimpleChIP® Human IκBα Promoter Primers #5552, human IL-8 promoter primers, and SimpleChIP® Human α Satellite Repeat Primers #4486. The amount of immunoprecipitated DNA in each sample is represented as signal relative to the total amount of input chromatin, which is equivalent to one.

Western Blotting

Western Blotting

Western blot analysis of extracts from wild-type, IKKα (-/-), and IKKβ (-/-) mouse embryonic fibroblasts (MEFs) using IKKβ (D30C6) Rabbit mAb (upper) and GAPDH (14C10) Rabbit mAb #2118 (lower).


Flow Cytometry

Flow Cytometry

Flow cytometric analysis of HCT 116 cells using IKKα (3G12) Mouse mAb (blue) compared to concentration-matched Mouse (G3A1) mAb IgG1 Isotype Control #5415 (red). Anti-mouse IgG (H+L), F(ab')2 Fragment (Alexa Fluor® 488 Conjugate) #4408 was used as a secondary antibody.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis using NF-κB p65 (D14E12) XP® Rabbit mAb on SignalSlide® NF-κB p65 IHC Controls #12873 (paraffin-embedded HCT116 cells, untreated (left) or treated with hTNF-α #8902 (right)).

Flow Cytometry

Flow Cytometry

Flow cytometric analysis of HeLa cells, untreated (blue) or TNF-α-treated (green), using Phospho-NF-κB p65 (Ser536) (93H1) Rabbit mAb compared to a nonspecific negative control antibody (red).


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human leiomyoma, using IκBα (L35A5) Mouse mAb (Amino-terminal Antigen).

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human gall bladder (chronic cholecystitis), using Phospho-IKKα/β (Ser176/180) (16A6) Rabbit mAb.

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human chronic cholecystitis using NF-κB p65 (D14E12) XP® Rabbit mAb.


IF-IC

IF-IC

Confocal immunofluorescent analysis of HCT 116 (high expression; left) and IGROV-1 (low expression; right) cells using IKKα (3G12) Mouse mAb (green). Blue pseudocolor = DRAQ5® #4084 (fluorescent DNA dye).

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human lung carcinoma, using IκBα (L35A5) Mouse mAb (Amino-terminal Antigen).

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human colon carcinoma, untreated (left) or λ phosphatase-treated (right), using Phospho-IKKα/β (Ser176/180) (16A6) Rabbit mAb.


IF-IC

IF-IC

Confocal immunofluorescent analysis of HeLa cells, serum starved (left) or TNF-α treated (#8902 at 20 ng/ml for 20 min, right), using Phospho-NF-κB p65 (Ser536) (93H1) Rabbit mAb (green). Actin filaments have been labeled with Alexa Fluor® phalloidin 555 (red).

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human renal adenocarcinoma, using IκBα (L35A5) Mouse mAb (Amino-terminal Antigen).

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human colon carcinoma, showing cytoplasmic localization, using Phospho-IKKα/β (Ser176/180) (16A6) Rabbit mAb.


IF-IC

IF-IC

Confocal immunofluorescent analysis of HT-1080 cells, untreated (left) or treated with hTNF-α #8902 (20 ng/ml, 20 min) (right), using NF-κB p65 (D14E12) XP® Rabbit mAb (green). Actin filaments were labeled with DY-554 phalloidin (red). Blue pseudocolor = DRAQ5® #4084 (fluorescent DNA dye).

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human lung (chronic bronchitis), using Phospho-IKKα/β (Ser176/180) (16A6) Rabbit mAb.

Flow Cytometry

Flow Cytometry

Flow cytometric analysis of HeLa cells, using IκBα (L35A5) Mouse mAb (Amino-terminal Antigen) (blue) compared to a nonspecifc negative control antibody (red).


IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human breast carcinoma, using Phospho-IKKα/β (Ser176/180) (16A6) Rabbit mAb in the presence of control peptide (left) or Phospho-IKK-alpha/beta (Ser176/180) Blocking Peptide #1023 (right).

IF-IC

IF-IC

Confocal immunofluorescent analysis of HeLa cells, untreated (left), or TNF-α-treated (#8902, 10 ng/ml for 15 min, right) using IκBα (L35A5) Mouse mAb (Amino-terminal Antigen) (red). Blue pseudocolor = DRAQ5® #4084 (fluorescent DNA dye).

IHC-F (frozen)

IHC-F (frozen)

Immunohistochemical analysis of frozen H1650 xenograft, showing cytoplasmic localization using Phospho-IKKα/β (Ser176/180)(16A6) Rabbit mAb.


Flow Cytometry

Flow Cytometry

Flow cytometric analysis of THP-1 cells, untreated (blue) and with TPA and LPS (green) using IKK-α (Ser176/Ser180) phosphate Rabbit mAb. Anti-rabbit IgG (H+L), F(ab')2 Fragment (PE Conjugate) #8885 was used as a secondary antibody.

バックグラウンド

The transcriptional nuclear factor κB (NF-κB)/Rel transcription factors are present in the cytosol in an inactive state, complexed with the inhibitory IκB proteins. Activation occurs via phosphorylation of IκBα at Ser32 and Ser36, resulting in the ubiquitin-mediated proteasome-dependent degradation of IκBα and the release and nuclear translocation of active NF-κB dimers. The regulation of IκBβ and IκBε is similar to that of IκBα, however, the phosphorylation and degradation of these proteins occurs with much slower kinetics. Phosphorylation of IκBβ occurs at Ser/Thr19 and Ser23, while IκBε can be phosphorylated at Ser18 and Ser22. The key regulatory step in this pathway involves activation of a high molecular weight IkappaB kinase (IKK) complex, consisting of three tightly associated IKK subunits. IKKα and IKKβ serve as the catalytic subunits of the kinase. Activation of IKK depends on phosphorylation at Ser177 and Ser181 in the activation loop of IKKβ (176 and 180 in IKKα). NF-κB-inducing kinase (NIK), TANK-binding kinase 1 (TBK1), and its homolog IKKε (IKKi), phosphorylate and activate IKKα and IKKβ.

The NF-κB family of transcription factors is comprised of five proteins in mammals, p65/RelA, c-Rel, RelB, NF-κB1 (p105/p50) and NF-κB2 (p100/p52). p105 and p100 are proteolytically processed to produce p50 and p52, respectively. The 50 kDa active form is produced through proteolytic processing following IKK-mediated phosphorylation of p105 at multiple sites (Ser922, 924, 928 and 933), while p100's processing to p52 is induced by phosphorylation of Ser864 and Ser868. The p50 and p52 products form dimeric complexes with Rel proteins, which are then able to bind DNA and regulate transcription. Phosphorylation of p65/RelA at Ser276 by PKA C and MSK1 enhances transcriptional activity. p65 phosphorylation at Ser536 regulates activation, nuclear localization, protein-protein interactions, and transcriptional activity. PMA-induced NF-κB transcriptional activity is dependent on the region of p65 containing the potential phosphorylation sites Ser457, Thr458, Thr464 and Ser468. Phosphorylation of Ser468 by GSK-3β inhibits basal p65 activity.

使用例
製品をご使用いただいて研究を発表されましたら、ぜひお知らせください

関連製品
2370   IKKβ (2C8) Rabbit mAb
2685   IKKγ Antibody
2689   Phospho-IKKγ (Ser376) Antibody
3013   TBK1/NAK Antibody
3035   NF-κB1 p105/p50 Antibody
3039   Phospho-NF-κB p65 (Ser468) Antibody
4727   c-Rel Antibody
4806   Phospho-NF-κB p105 (Ser933) (18E6) Rabbit mAb
4810   Phospho-NF-κB2 p100 (Ser866/870) Antibody
4812   IκBα (44D4) Rabbit mAb
4882   NF-κB2 p100/p52 Antibody
4954   RelB Antibody
4994   NIK Antibody
8902   Human Tumor Necrosis Factor-α (hTNF-α)
9243   NF-κB Control Cell Extracts
9246   Phospho-IκBα (Ser32/36) (5A5) Mouse mAb

Illumina is a registered trademark of Illumina, Inc.
DRAQ5 is a registered trademark of Biostatus Limited.
XP is a registered trademark of Cell Signaling Technology, Inc.
Alexa Fluor is a registered trademark of Life Technologies Corporation.
LumiGLO is a registered trademark of Kirkegaard & Perry Laboratories.
Cell Signaling Technology is a trademark of Cell Signaling Technology, Inc.
U.S. Patent No. 7,429,487, foreign equivalents, and child patents deriving therefrom.

本製品は試験研究用です。
